Shelf Reinforcement Rail
Shelf Reinforcement Rail is an adjustable shelf support that seats into a line-bored hole to carry cabinet, bookcase, or glass shelves at the height you choose. It is available for OEM bulk supply with samples, datasheets, and installation drawings on request.
Download PDFOverview
Shelf Reinforcement Rail is an adjustable shelf support that seats into a line-bored hole to carry cabinet, bookcase, or glass shelves at the height you choose. The notes below cover construction, selection factors, sizes, materials, finishes, application fit, and installation for OEM production.
Industry Data
Use these product signals to compare fit, specification risk, and sourcing options before requesting samples or bulk pricing.
- Cabinet Width: 400 mm Confirm the exact value on the order datasheet before production.
- Load Capacity: 30 kg Confirm the exact value on the order datasheet before production.
- Runner / Motion: Lift-up assist Confirm the exact value on the order datasheet before production.
- Basket / Frame Size: Two-tier basket Confirm the exact value on the order datasheet before production.
- Mounting: Corner cabinet pivot mount Confirm the exact value on the order datasheet before production.
- Material options: Stainless Steel, Carbon Steel, Zinc Alloy, Aluminum and Brass Choose material by strength, corrosion exposure, and target price.
- Finish options: Polished Stainless Steel, White, Aged Brass, Satin Chrome and Galvanized Confirm finish samples when color matching matters.
- Application fit: Woodworking Projects, MDF Cabinets, Plywood Cabinets and Solid Wood Furniture Match the product to the furniture use case, not only to the part name.
Key Specifications
| Cabinet Width | 400 mm |
|---|---|
| Load Capacity | 30 kg |
| Runner / Motion | Lift-up assist |
| Basket / Frame Size | Two-tier basket |
| Mounting | Corner cabinet pivot mount |
| Material / Finish | Chrome-plated steel wire |
| Door Compatibility | Hinged door cabinet |
Specifications are configurable for OEM/ODM orders. Exact values are confirmed on the datasheet for your order.
