Opening Arm
Opening Arm supports an upward-opening cabinet flap, holding it open and lowering it smoothly, sized by door weight and height. It is available for OEM bulk supply with samples, datasheets, and installation drawings on request.
Download PDFOverview
Opening Arm supports an upward-opening cabinet flap, holding it open and lowering it smoothly, sized by door weight and height. This page summarizes how to specify it for volume furniture and cabinet manufacturing, including the dimensions and options that matter most to buyers.
Industry Data
Use these product signals to compare fit, specification risk, and sourcing options before requesting samples or bulk pricing.
- Lift Force: 80 N Confirm the exact value on the order datasheet before production.
- Stroke Length: 100 mm Confirm the exact value on the order datasheet before production.
- Extended Length: 265 mm Confirm the exact value on the order datasheet before production.
- Door Weight Range: 4-8 kg per pair Confirm the exact value on the order datasheet before production.
- Opening Angle: Up to 110 deg Confirm the exact value on the order datasheet before production.
- Material options: Stainless Steel, Carbon Steel, Zinc Alloy, Aluminum and Brass Choose material by strength, corrosion exposure, and target price.
- Finish options: Black Nickel, Champagne Bronze, Flat Black, Gold and Satin Brass Confirm finish samples when color matching matters.
- Application fit: Bathroom Vanities, Wardrobe Cabinets, Closet Systems and Bedroom Furniture Match the product to the furniture use case, not only to the part name.
Key Specifications
| Lift Force | 80 N |
|---|---|
| Stroke Length | 100 mm |
| Extended Length | 265 mm |
| Door Weight Range | 4-8 kg per pair |
| Opening Angle | Up to 110 deg |
| Mounting | Side panel bracket |
| Damping | Soft-close |
Specifications are configurable for OEM/ODM orders. Exact values are confirmed on the datasheet for your order.
How to Choose
- Door weight and height to size the force
- Lift type: flap stay, gas strut, or mechanical lift system
- Opening angle and stay position
- Soft-close damping
Material Options
Steel cylinders with nitrogen charge; plated for corrosion resistance.
Finish Options
Typically gray or nickel and mostly hidden inside the cabinet.
Application Fit
- Bathroom Vanities
- For this application, opening arm is specified for humidity and corrosion resistance, compact drawers, and easy maintenance.
- Wardrobe Cabinets
- For this application, opening arm is specified for quiet operation, smooth movement, and space-saving storage.
- Closet Systems
- For this application, opening arm is specified for the typical load, environment, and usage of this application.
- Bedroom Furniture
- For this application, opening arm is specified for the typical load, environment, and usage of this application.
- Living Room Furniture
- For this application, opening arm is specified for the typical load, environment, and usage of this application.
- Office Furniture
- For this application, opening arm is specified for high-frequency use, file-drawer loads, and central locking.
Recommended for These Applications
Installation Notes
Fix the bracket positions to the geometry chart, then test the hold-open and soft stop.
⇲ Animated Installation Guide
Step-by-step SVG diagrams for installing Opening Arm on a production line.
Open the installation guide →Buying Notes for OEM Orders
Confirm force class against a sample flap; standardize brackets across the range.
Comparisons
