Gas Strut
Gas Strut supports an upward-opening cabinet flap, holding it open and lowering it smoothly, sized by door weight and height. It is available for OEM bulk supply with samples, datasheets, and installation drawings on request.
Download PDFOverview
Gas Strut supports an upward-opening cabinet flap, holding it open and lowering it smoothly, sized by door weight and height. This page summarizes how to specify it for volume furniture and cabinet manufacturing, including the dimensions and options that matter most to buyers.
Industry Data
Use these product signals to compare fit, specification risk, and sourcing options before requesting samples or bulk pricing.
- Lift Force: 60 N Confirm the exact value on the order datasheet before production.
- Stroke Length: 100 mm Confirm the exact value on the order datasheet before production.
- Extended Length: 350 mm Confirm the exact value on the order datasheet before production.
- Door Weight Range: 2-5 kg per pair Confirm the exact value on the order datasheet before production.
- Opening Angle: Up to 110 deg Confirm the exact value on the order datasheet before production.
- Material options: Stainless Steel, Carbon Steel, Zinc Alloy, Aluminum and Brass Choose material by strength, corrosion exposure, and target price.
- Finish options: Gray, Copper, Bronze, Powder Coated and Satin Chrome Confirm finish samples when color matching matters.
- Application fit: Chest of Drawers, RV and Camper Furniture, Truck and Tool Storage and Face Frame Cabinets Match the product to the furniture use case, not only to the part name.
Key Specifications
| Lift Force | 60 N |
|---|---|
| Stroke Length | 100 mm |
| Extended Length | 350 mm |
| Door Weight Range | 2-5 kg per pair |
| Opening Angle | Up to 110 deg |
| Mounting | Side panel bracket |
| Damping | Soft-close |
Specifications are configurable for OEM/ODM orders. Exact values are confirmed on the datasheet for your order.
How to Choose
- Door weight and height to size the force
- Lift type: flap stay, gas strut, or mechanical lift system
- Opening angle and stay position
- Soft-close damping
Material Options
Steel cylinders with nitrogen charge; plated for corrosion resistance.
Finish Options
Typically gray or nickel and mostly hidden inside the cabinet.
Application Fit
- Chest of Drawers
- For this application, gas strut is specified for the typical load, environment, and usage of this application.
- RV and Camper Furniture
- For this application, gas strut is specified for the typical load, environment, and usage of this application.
- Truck and Tool Storage
- For this application, gas strut is specified for the typical load, environment, and usage of this application.
- Face Frame Cabinets
- For this application, gas strut is specified for the typical load, environment, and usage of this application.
- Frameless Cabinets
- For this application, gas strut is specified for the typical load, environment, and usage of this application.
- Kitchen Cabinets
- For this application, gas strut is specified for daily use, soft-close motion, moisture resistance, and fast, repeatable installation on the line.
Recommended for These Applications
Installation Notes
Fix the bracket positions to the geometry chart, then test the hold-open and soft stop.
⇲ Animated Installation Guide
Step-by-step SVG diagrams for installing Gas Strut on a production line.
Open the installation guide →Buying Notes for OEM Orders
Confirm force class against a sample flap; standardize brackets across the range.
Comparisons
