Bi Fold Lift System
Bi Fold Lift System supports an upward-opening cabinet flap, holding it open and lowering it smoothly, sized by door weight and height. It is available for OEM bulk supply with samples, datasheets, and installation drawings on request.
Download PDFOverview
Bi Fold Lift System supports an upward-opening cabinet flap, holding it open and lowering it smoothly, sized by door weight and height. The notes below cover construction, selection factors, sizes, materials, finishes, application fit, and installation for OEM production.
Industry Data
Use these product signals to compare fit, specification risk, and sourcing options before requesting samples or bulk pricing.
- Lift Force: 60 N Confirm the exact value on the order datasheet before production.
- Stroke Length: 150 mm Confirm the exact value on the order datasheet before production.
- Extended Length: 245 mm Confirm the exact value on the order datasheet before production.
- Door Weight Range: 6-12 kg per pair Confirm the exact value on the order datasheet before production.
- Opening Angle: 90-105 deg Confirm the exact value on the order datasheet before production.
- Material options: Stainless Steel, Carbon Steel, Zinc Alloy, Aluminum and Brass Choose material by strength, corrosion exposure, and target price.
- Finish options: Powder Coated, Antique Brass, Galvanized, Black Nickel and Gold Confirm finish samples when color matching matters.
- Application fit: RV and Camper Furniture, Truck and Tool Storage, Face Frame Cabinets and Frameless Cabinets Match the product to the furniture use case, not only to the part name.
Key Specifications
| Lift Force | 60 N |
|---|---|
| Stroke Length | 150 mm |
| Extended Length | 245 mm |
| Door Weight Range | 6-12 kg per pair |
| Opening Angle | 90-105 deg |
| Mounting | Ball-stud bracket |
| Damping | Free-stop friction |
Specifications are configurable for OEM/ODM orders. Exact values are confirmed on the datasheet for your order.
