European hinge
European hinge is a concealed cabinet hinge that attaches inside the cabinet so no hardware shows on the door face, giving adjustable, repeatable door alignment in volume furniture production. It is available for OEM bulk supply with samples, datasheets, and installation drawings on request.
Download PDFOverview
European hinge is a concealed cabinet hinge that attaches inside the cabinet so no hardware shows on the door face, giving adjustable, repeatable door alignment in volume furniture production. The notes below cover construction, selection factors, sizes, materials, finishes, application fit, and installation for OEM production.
Industry Data
Use these product signals to compare fit, specification risk, and sourcing options before requesting samples or bulk pricing.
- Cup Diameter: 35 mm Confirm the exact value on the order datasheet before production.
- Cup Depth: 13 mm Confirm the exact value on the order datasheet before production.
- Opening Angle: 120 deg Confirm the exact value on the order datasheet before production.
- Overlay / Crank: Inset Confirm the exact value on the order datasheet before production.
- Door Thickness: 18-25 mm Confirm the exact value on the order datasheet before production.
- Material options: Stainless Steel, Carbon Steel, Zinc Alloy, Aluminum and Brass Choose material by strength, corrosion exposure, and target price.
- Finish options: Anodized Aluminum, Black Nickel, Antique Brass, Powder Coated and Brushed Stainless Steel Confirm finish samples when color matching matters.
- Application fit: Kitchen Cabinets, Custom Cabinets, Wardrobe Cabinets and Woodworking Projects Match the product to the furniture use case, not only to the part name.
Key Specifications
| Cup Diameter | 35 mm |
|---|---|
| Cup Depth | 13 mm |
| Opening Angle | 120 deg |
| Overlay / Crank | Inset |
| Door Thickness | 18-25 mm |
| Mounting Pattern | Screw-on mounting plate |
| Closing Function | Self closing |
Specifications are configurable for OEM/ODM orders. Exact values are confirmed on the datasheet for your order.
How to Choose
- Cup diameter (35mm is the furniture-industry standard; 26mm for thin doors)
- Cup depth and the required boring pattern
- Opening angle (95°–110° for most doors, wide-angle for blind corners)
- Overlay type: full overlay, half overlay, or inset
- Face-frame vs frameless (European) cabinet construction
- Door thickness and material
- Soft-close or self-closing requirement
- Mounting plate type and clip-on vs screw-on attachment
Material Options
Cold-rolled steel arms with nickel plating are standard for value, while stainless steel suits humid kitchens and bathrooms. Cup and arm gauge drive the cycle life and sag resistance.
Finish Options
Hinges are usually nickel-plated and hidden inside the cabinet, so finish is about corrosion resistance rather than appearance. Specify a heavier plating or stainless steel for high-humidity programs.
Application Fit
- Kitchen Cabinets
- For this application, european hinge is specified for daily use, soft-close motion, moisture resistance, and fast, repeatable installation on the line.
- Custom Cabinets
- For this application, european hinge is specified for the typical load, environment, and usage of this application.
- Wardrobe Cabinets
- For this application, european hinge is specified for quiet operation, smooth movement, and space-saving storage.
- Woodworking Projects
- For this application, european hinge is specified for the typical load, environment, and usage of this application.
- MDF Cabinets
- For this application, european hinge is specified for the typical load, environment, and usage of this application.
- Plywood Cabinets
- For this application, european hinge is specified for the typical load, environment, and usage of this application.
Recommended for These Applications
Installation Notes
Bore the 35mm cup, screw the hinge boss to the door, fix the mounting plate to the cabinet side at the correct height, then clip the arm to the plate. Use the three adjustment screws to align overlay, height, and depth.
⇲ Animated Installation Guide
Step-by-step SVG diagrams for installing European hinge on a production line.
Open the installation guide →Buying Notes for OEM Orders
For OEM cabinet lines, lock the cup size, opening angle, overlay, and soft-close type, then standardize the mounting plate height across the range to keep boring patterns consistent.
