Piano Hinge for Aluminum Frame Cabinet Doors

Request a Quote All Piano Hinge Variants

Overview

For this application, piano hinge is specified for the typical load, environment, and usage of this application. It must handle the typical demands of aluminum frame cabinet doors while matching the surrounding furniture finish.

See the full Piano Hinge page for all sizes, materials, finishes, and specifications.

Industry Data

Use these product signals to compare fit, specification risk, and sourcing options before requesting samples or bulk pricing.

Open Length: 300 mm Confirm the exact value on the order datasheet before production.
Leaf Width: 25 mm Confirm the exact value on the order datasheet before production.
Pin Diameter: 3.0 mm Confirm the exact value on the order datasheet before production.
Material Thickness: 1.0 mm Confirm the exact value on the order datasheet before production.
Hole Spacing: 100 mm Confirm the exact value on the order datasheet before production.
Material options: Stainless Steel, Carbon Steel, Zinc Alloy, Aluminum and Brass Choose material by strength, corrosion exposure, and target price.
Finish options: Stainless Steel, White, Brushed Stainless Steel, Chrome and Black Nickel Confirm finish samples when color matching matters.
Application fit: Aluminum Frame Cabinet Doors, Handleless Cabinets, Soft Close Cabinets and Push To Open Cabinets Match the product to the furniture use case, not only to the part name.

Key Specifications

Open Length	300 mm
Leaf Width	25 mm
Pin Diameter	3.0 mm
Material Thickness	1.0 mm
Hole Spacing	100 mm
Material / Finish	Zinc-plated steel

Values are configurable for OEM/ODM orders and confirmed on your datasheet.

Selection Factors

Cup diameter (35mm is the furniture-industry standard; 26mm for thin doors)
Cup depth and the required boring pattern
Opening angle (95°–110° for most doors, wide-angle for blind corners)
Overlay type: full overlay, half overlay, or inset
Face-frame vs frameless (European) cabinet construction
Door thickness and material

Installation Notes

Bore the 35mm cup, screw the hinge boss to the door, fix the mounting plate to the cabinet side at the correct height, then clip the arm to the plate. Use the three adjustment screws to align overlay, height, and depth.
