Zinc Alloy Hinge Repair Plate
Overview
Zinc Alloy is chosen for hinge repair plate when the application demands its particular corrosion and strength profile. It pairs with compatible finishes to meet the target market and price point.
See the full Hinge Repair Plate page for all sizes, materials, finishes, and specifications.
Industry Data
Use these product signals to compare fit, specification risk, and sourcing options before requesting samples or bulk pricing.
- Cup Diameter: 35 mm Confirm the exact value on the order datasheet before production.
- Cup Depth: 13 mm Confirm the exact value on the order datasheet before production.
- Opening Angle: 105 deg Confirm the exact value on the order datasheet before production.
- Overlay / Crank: Blind corner Confirm the exact value on the order datasheet before production.
- Door Thickness: 16-22 mm Confirm the exact value on the order datasheet before production.
- Material options: Stainless Steel, Carbon Steel, Zinc Alloy, Aluminum and Brass Choose material by strength, corrosion exposure, and target price.
- Finish options: Brushed Stainless Steel, Gray, Satin Nickel, Satin Brass and Rose Gold Confirm finish samples when color matching matters.
- Application fit: Soft Close Cabinets, Push To Open Cabinets, Heavy Duty Drawers and File Cabinets Match the product to the furniture use case, not only to the part name.
Key Specifications
| Cup Diameter | 35 mm |
|---|---|
| Cup Depth | 13 mm |
| Opening Angle | 105 deg |
| Overlay / Crank | Blind corner |
| Door Thickness | 16-22 mm |
| Mounting Pattern | 45/9.5 mm cup screw pattern |
| Closing Function | Free swing |
Values are configurable for OEM/ODM orders and confirmed on your datasheet.
Selection Factors
- Cup diameter (35mm is the furniture-industry standard; 26mm for thin doors)
- Cup depth and the required boring pattern
- Opening angle (95°–110° for most doors, wide-angle for blind corners)
- Overlay type: full overlay, half overlay, or inset
- Face-frame vs frameless (European) cabinet construction
- Door thickness and material
Installation Notes
Bore the 35mm cup, screw the hinge boss to the door, fix the mounting plate to the cabinet side at the correct height, then clip the arm to the plate. Use the three adjustment screws to align overlay, height, and depth.
