Overview
Butt Hinge is a concealed cabinet hinge that attaches inside the cabinet so no hardware shows on the door face, giving adjustable, repeatable door alignment in volume furniture production. The notes below cover construction, selection factors, sizes, materials, finishes, application fit, and installation for OEM production.
Specifications & Options
| Cup Diameter | 35 mm · 26 mm for thin doors |
|---|---|
| Cup Depth | 11.5 mm · 12 mm · 13 mm |
| Opening Angle | 95 deg · 105 deg · 110 deg · 120 deg |
| Overlay / Crank | Full overlay · Half overlay · Inset · Blind corner |
| Door Thickness | 14-20 mm · 16-22 mm · 18-25 mm |
| Mounting Pattern | 45/9.5 mm cup screw pattern · 48/6 mm cup screw pattern · Clip-on mounting plate · Screw-on mounting plate |
| Closing Function | Self closing · Soft-close optional · Free swing |
Ranges show what we supply for this product type. Your exact values are fixed on the order datasheet.
How to Choose
- Cup diameter (35mm is the furniture-industry standard; 26mm for thin doors)
- Cup depth and the required boring pattern
- Opening angle (95°–110° for most doors, wide-angle for blind corners)
- Overlay type: full overlay, half overlay, or inset
- Face-frame vs frameless (European) cabinet construction
- Door thickness and material
- Soft-close or self-closing requirement
- Mounting plate type and clip-on vs screw-on attachment
Materials & Finishes
Materials
Cold-rolled steel arms with nickel plating are standard for value, while stainless steel suits humid kitchens and bathrooms. Cup and arm gauge drive the cycle life and sag resistance.
- Stainless Steel
- Carbon Steel
- Zinc Alloy
- Aluminum
- Brass
- Copper
Finishes
Hinges are usually nickel-plated and hidden inside the cabinet, so finish is about corrosion resistance rather than appearance. Specify a heavier plating or stainless steel for high-humidity programs.
- Satin Chrome
- Zinc Plated
- Aged Brass
- Polished Chrome
- Oil Rubbed Bronze
- White
- Galvanized
- Gold
Application Fit
- Aluminum Frame Cabinet Doors
- For this application, butt hinge is specified for the typical load, environment, and usage of this application.
- Handleless Cabinets
- For this application, butt hinge is specified for the typical load, environment, and usage of this application.
- Soft Close Cabinets
- For this application, butt hinge is specified for the typical load, environment, and usage of this application.
- Push To Open Cabinets
- For this application, butt hinge is specified for the typical load, environment, and usage of this application.
- Heavy Duty Drawers
- For this application, butt hinge is specified for the typical load, environment, and usage of this application.
- File Cabinets
- For this application, butt hinge is specified for full-extension access and load-rated, lockable operation.
Installation Notes
Bore the 35mm cup, screw the hinge boss to the door, fix the mounting plate to the cabinet side at the correct height, then clip the arm to the plate. Use the three adjustment screws to align overlay, height, and depth.
Animated installation guide Step-by-step diagrams for installing Butt Hinge on a production line.Buying Notes for OEM Orders
For OEM cabinet lines, lock the cup size, opening angle, overlay, and soft-close type, then standardize the mounting plate height across the range to keep boring patterns consistent.
