35Mm Cup Hinge for Kitchen Cabinets
Overview
For this application, 35mm cup hinge is specified for daily use, soft-close motion, moisture resistance, and fast, repeatable installation on the line. It must handle the typical demands of kitchen cabinets while matching the surrounding furniture finish.
See the full 35Mm Cup Hinge page for all sizes, materials, finishes, and specifications.
Industry Data
Use these product signals to compare fit, specification risk, and sourcing options before requesting samples or bulk pricing.
- Cup Diameter: 35 mm Confirm the exact value on the order datasheet before production.
- Cup Depth: 12 mm Confirm the exact value on the order datasheet before production.
- Opening Angle: 105 deg Confirm the exact value on the order datasheet before production.
- Overlay / Crank: Inset Confirm the exact value on the order datasheet before production.
- Door Thickness: 18-25 mm Confirm the exact value on the order datasheet before production.
- Material options: Stainless Steel, Carbon Steel, Zinc Alloy, Aluminum and Brass Choose material by strength, corrosion exposure, and target price.
- Finish options: Stainless Steel, Champagne Bronze, Satin Gold, Rose Gold and Brushed Brass Confirm finish samples when color matching matters.
- Application fit: Kitchen Cabinets, Custom Cabinets, Truck and Tool Storage and Face Frame Cabinets Match the product to the furniture use case, not only to the part name.
Key Specifications
| Cup Diameter | 35 mm |
|---|---|
| Cup Depth | 12 mm |
| Opening Angle | 105 deg |
| Overlay / Crank | Inset |
| Door Thickness | 18-25 mm |
| Mounting Pattern | Screw-on mounting plate |
| Closing Function | Soft-close optional |
Values are configurable for OEM/ODM orders and confirmed on your datasheet.
Selection Factors
- Cup diameter (35mm is the furniture-industry standard; 26mm for thin doors)
- Cup depth and the required boring pattern
- Opening angle (95°–110° for most doors, wide-angle for blind corners)
- Overlay type: full overlay, half overlay, or inset
- Face-frame vs frameless (European) cabinet construction
- Door thickness and material
Installation Notes
Bore the 35mm cup, screw the hinge boss to the door, fix the mounting plate to the cabinet side at the correct height, then clip the arm to the plate. Use the three adjustment screws to align overlay, height, and depth.
⇲ Animated Installation Guide
Step-by-step SVG diagrams for installing 35Mm Cup Hinge.
Open the installation guide →Related Applications
