Overview
Display Case Lock mounts and secures glass doors and shelves in display and retail cabinets, sized to the glass thickness. The notes below cover construction, selection factors, sizes, materials, finishes, application fit, and installation for OEM production.
Specifications & Options
| Lock Type | Cam lock · Drawer lock · Plunger lock · Sliding-door lock · Central locking system · Electronic cabinet lock |
|---|---|
| Cylinder Length | 16 mm · 20 mm · 22 mm · 25 mm · 30 mm |
| Panel Thickness | 12-18 mm · 16-22 mm · 18-25 mm |
| Cam Throw / Reach | 90 deg cam rotation · 180 deg cam rotation · 12 mm throw · 22 mm straight cam · Offset cam supplied |
| Keying Option | Keyed alike · Keyed different · Master key system available · RFID card / keypad programmable |
| Finish | Chrome · Nickel · Black · Brushed stainless |
| Supplied With | 2 keys and strike plate · Cam, nut, and rosette · Battery box and override key · Lock rod and brackets |
Ranges show what we supply for this product type. Your exact values are fixed on the order datasheet.
How to Choose
- Glass thickness and edge support
- Glass-door hinges and clamps
- Showcase locks and security
- Display lighting integration
Materials & Finishes
Materials
Chromed zinc and stainless for a clean display look.
- Stainless Steel
- Carbon Steel
- Zinc Alloy
- Aluminum
- Brass
- Copper
Finishes
Chrome, satin nickel, and clear to keep the focus on the product.
- Flat Black
- Bronze
- Copper
- Brushed Nickel
- Satin Brass
- Polished Brass
- White
- Polished Chrome
Application Fit
- Truck and Tool Storage
- For this application, display case lock is specified for the typical load, environment, and usage of this application.
- Face Frame Cabinets
- For this application, display case lock is specified for the typical load, environment, and usage of this application.
- Frameless Cabinets
- For this application, display case lock is specified for the typical load, environment, and usage of this application.
- Kitchen Cabinets
- For this application, display case lock is specified for daily use, soft-close motion, moisture resistance, and fast, repeatable installation on the line.
- Bathroom Vanities
- For this application, display case lock is specified for humidity and corrosion resistance, compact drawers, and easy maintenance.
- Wardrobe Cabinets
- For this application, display case lock is specified for quiet operation, smooth movement, and space-saving storage.
Installation Notes
Fit cushioned clamps to the glass, set hinges to swing clear, and align doors.
Animated installation guide Step-by-step diagrams for installing Display Case Lock on a production line.Buying Notes for OEM Orders
Standardize glass thicknesses and clamp types across display fixtures.
