Wood Lock Cylinder
Overview
Wood is chosen for lock cylinder when the application demands its particular corrosion and strength profile. It pairs with compatible finishes to meet the target market and price point.
See the full Lock Cylinder page for all sizes, materials, finishes, and specifications.
Industry Data
Use these product signals to compare fit, specification risk, and sourcing options before requesting samples or bulk pricing.
- Lock Type: Drawer lock Confirm the exact value on the order datasheet before production.
- Cylinder Length: 20 mm Confirm the exact value on the order datasheet before production.
- Panel Thickness: 16-22 mm Confirm the exact value on the order datasheet before production.
- Cam Throw / Reach: Offset cam supplied Confirm the exact value on the order datasheet before production.
- Keying Option: Master key system available Confirm the exact value on the order datasheet before production.
- Material options: Stainless Steel, Carbon Steel, Zinc Alloy, Aluminum and Brass Choose material by strength, corrosion exposure, and target price.
- Finish options: Galvanized, Matte Black, Anodized Aluminum, Aged Brass and Antique Brass Confirm finish samples when color matching matters.
- Application fit: Restaurant Furniture, Outdoor Furniture, RV Furniture and Marine Furniture Match the product to the furniture use case, not only to the part name.
Key Specifications
| Lock Type | Drawer lock |
|---|---|
| Cylinder Length | 20 mm |
| Panel Thickness | 16-22 mm |
| Cam Throw / Reach | Offset cam supplied |
| Keying Option | Master key system available |
| Finish | Chrome |
| Supplied With | Cam, nut, and rosette |
Values are configurable for OEM/ODM orders and confirmed on your datasheet.
Selection Factors
- Lock type: cam lock, drawer lock, sliding-door lock, or central locking
- Cabinet material and panel thickness
- Keyed-alike vs keyed-different for fleets
- Cylinder length and cam reach
- Security level and frequency of use
Installation Notes
Bore the cylinder hole, fit the cam to the correct throw, and test against the strike before volume.
