Pantry Pull Out Slide for Soft Close Cabinets
Overview
For this application, pantry pull out slide is specified for the typical load, environment, and usage of this application. It must handle the typical demands of soft close cabinets while matching the surrounding furniture finish.
See the full Pantry Pull Out Slide page for all sizes, materials, finishes, and specifications.
Industry Data
Use these product signals to compare fit, specification risk, and sourcing options before requesting samples or bulk pricing.
- Nominal Length: 22 in Confirm the exact value on the order datasheet before production.
- Extension Type: Over-travel Confirm the exact value on the order datasheet before production.
- Load Rating: 75 lb Confirm the exact value on the order datasheet before production.
- Mounting Clearance: Side mount, 12.5 mm per side Confirm the exact value on the order datasheet before production.
- Member Height: 45 mm Confirm the exact value on the order datasheet before production.
- Material options: Stainless Steel, Carbon Steel, Zinc Alloy, Aluminum and Brass Choose material by strength, corrosion exposure, and target price.
- Finish options: Chrome, Powder Coated, Antique Brass, Pewter and Black Nickel Confirm finish samples when color matching matters.
- Application fit: Soft Close Cabinets, Push To Open Cabinets, Heavy Duty Drawers and File Cabinets Match the product to the furniture use case, not only to the part name.
Key Specifications
| Nominal Length | 22 in |
|---|---|
| Extension Type | Over-travel |
| Load Rating | 75 lb |
| Mounting Clearance | Side mount, 12.5 mm per side |
| Member Height | 45 mm |
| Motion Feature | Self close |
| Cycle Test | 80,000 cycles |
Values are configurable for OEM/ODM orders and confirmed on your datasheet.
Selection Factors
- Slide length matched to the cabinet/drawer depth
- Extension type: full extension, over-travel, or partial
- Mounting type: side mount, undermount, bottom mount, or center mount
- Load capacity for the drawer contents and usage
- Side clearance available in the cabinet opening
- Soft-close, push-to-open, or lockable function
Installation Notes
Mount the cabinet member level and square, fix the drawer member to the drawer side at the matching height, then engage and test full travel. Verify clearance and that soft-close engages before locking the pattern.
